Description

High-Quality Image with 8MP, 1/2.8″ CMOS Sensor

• This camera boasts an 8-megapixel CMOS sensor with a 1/2.8″ size, offering superior image resolution and detail. The high-resolution sensor captures images with exceptional clarity, making it ideal for applications requiring precise and detailed visual information. The CMOS technology enhances performance in varying lighting conditions, including low light, and ensures efficient power usage.

Available Resolutions and Frame Rates:

• 8MP (3840×2160) at 15 frames per second: Delivers ultra-high-definition video with impressive detail and clarity, though at a lower frame rate of 15 fps. This resolution is perfect for capturing detailed and expansive scenes with high accuracy, especially in environments where high-resolution is crucial.
• 5MP (2592×1944) at 25/20 frames per second: Provides high-definition video with excellent detail and smooth playback at either 25 or 20 frames per second. This resolution offers a balance between high detail and performance, suitable for a wide range of surveillance needs.
• 4MP (2592×1520) at 25/20 frames per second: Offers a good combination of high resolution and smooth frame rates, making it suitable for general surveillance where clarity and performance are important but not at the highest levels.
• 3MP (2304×1296) at 25/20 frames per second: Provides a slightly lower resolution while maintaining smooth video capture, ideal for general monitoring where high detail is beneficial but not essential.
• 2MP (1920×1080) at 30/25 frames per second: Standard Full HD resolution with a higher frame rate of up to 30 or 25 frames per second, ensuring smooth video playback. This resolution is commonly used for various security applications due to its balance of image quality and performance.

Video Compression Formats: H.265, H.264

• H.265 (HEVC): The latest video compression standard that delivers higher efficiency by significantly reducing file sizes and bandwidth usage while maintaining high video quality. H.265 is ideal for high-definition video streaming and storage, optimizing both bandwidth and storage requirements.
• H.264 (AVC): A widely used video compression format known for its effective balance between image quality and file size. H.264 provides broad compatibility with a range of devices and systems, making it a reliable choice for video management.

Smart IR with Up to 20m IR Distance

• Equipped with Smart Infrared (IR) technology, this camera can capture clear images in complete darkness with an effective IR range of up to 20 meters. This feature ensures reliable night-time surveillance and visibility in low-light or no-light conditions, providing enhanced security around the clock.

Wide Dynamic Range (WDR)

• WDR technology improves the camera’s ability to handle scenes with both very bright and very dark areas by adjusting the exposure levels. This ensures that both highlights and shadows are visible and detailed, providing clear and balanced images in high-contrast lighting conditions.

3D Digital Noise Reduction (DNR)

• Uses 3D Digital Noise Reduction to minimize video noise and enhance image clarity, particularly in low-light environments. This technology filters out unwanted noise and maintains sharpness, resulting in clearer and more detailed video footage.

Power Supply Options: DC12V or PoE (IEEE 802.3af)

• The camera supports flexible power supply options, including a 12V DC adapter or Power over Ethernet (PoE) in compliance with IEEE 802.3af standards. PoE allows for both power and data transmission through a single Ethernet cable, simplifying installation and reducing the need for additional power cabling.
